Atom Reworked FDC

Information on how the build the Floppy Disk controller for my Acorn Atom Reworked computer. Circuit Diagram Parts List Name Designator Footprint Quantity 10nF C1 CAP_2.54_CERAMIC 1 100nF C2,C3,C4,C5,C6,C7,C8, C9,C10,C11,C12,C13 CAP_5MM 12 ATOM_EXP_64P EXP1 ATOM_EXP_64P_SINGLE 1 7438 IC1 DIP14 1 74LS00 IC2 DIP14 1 7406 IC3 DIP14 1 74LS04 IC4 DIP14 1 CD4013BD IC5,IC6 DIP14 […]
